System Diagram
| Item | Description |
|---|---|
| 1 | Private CAN |
| 2 | PCM |
| 3 | Message center display |
| 4 | LH upper steering wheel switch |
| 5 | ABS module |
| 6 | IPC |
| 7 | BCM |
| 8 | Door ajar switches |
| 9 | Parking brake switch |
| 10 | Brake fluid level switch |
| 11 | GWM |
| 12 | Washer fluid level switch |
| 13 | SODR |
| 14 | Fuel pump and sender unit |
| 15 | IPMA |
| 16 | PAM |
| 17 | Oil pressure sensor |
| 18 | HVAC module |
| 19 | SODL |
| 20 | Fuel level sensor |
| 21 | Ambient air temperature sensor |
| 22 | CCM |
| 23 | DSM |
| 24 | PSCM |
| 25 | SCCM |
| 26 | APIM |
