Camshaft Position (CMP) Sensor: Removal

WARNING: This page is about a different car, the 2024 Ford Transit-350 HD, 2024 Ford Transit-350, 2024 Ford Transit-250, and 2024 Ford Transit-150. However, it is still accessible from the selected car via links, so may be relevant.
    • Disconnect the CMP sensor connectors.

    • Remove the bolts and the CMP sensors.

GFD839168Courtesy of FORD MOTOR COMPANY
