Exploded View Of Intake Manifold
WARNING: This page is about a different variant/trim than selected.
| Item | Part Number | Description |
|---|---|---|
| 1 | -- | Fuel supply tube |
| 2 | -- | Coolant outlet |
| 3 | -- | EGR valve |
| 4 | -- | Electronic throttle body |
| 5 | -- | Cylinder head gasket |
| 6 | -- | Cylinder block |
| 7 | -- | Knock Sensor (KS) |
| 8 | -- | Intake manifold |
| 9 | -- | Intake manifold gasket |
| 10 | -- | Coolant hose |
| 11 | -- | Cylinder head |
| 12 | -- | Fuel injector (4 required) |
| 13 | -- | Fuel rail |
