Headliner - Crew Cab: Removal

WARNING: This page is about a different car, the 2018 Ford F-250 Super Duty. However, it is still accessible from the selected car via links, so may be relevant.

NOTE: Removal Steps In This Procedure May Contain Installation Details.

NOTE: Steering Wheel Should Be In The Full Inward And Upward Position For Headliner Removal.

Remove The Following Items:
1. On Both Sides. Remove The A-Pillar Trim Panels. Refer to: a-Pillar Trim Panel .
2. On Both Sides. Remove The B-Pillar Trim Panels. Refer to: b-Pillar Trim Panel - Crew Cab .
3. On Both Sides. Remove The C-Pillar Trim Panels. Refer to: c-Pillar Trim Panel .
4. On Both Sides. Remove The Front Seats. Refer to: Front Seat .
5. If Equipped. Remove The Front Center Seat. Refer to: Front Center Seat .
6. If Equipped. Remove The Floor Console. Refer to: Floor Console .
7. On Passenger Side. Remove The Front Door. Refer to: Front Door - Crew Cab/Regular Cab .
NOTE: LH Side Shown In Illustration, RH Side Similar.

On Both Sides. Remove The Sun Visor.
1. Remove The Screw Cover.
2. Remove The Screw.
3. Remove The Sun Visor.
4. If Equipped. Disconnect The Electrical Connector.
Courtesy of FORD MOTOR COMPANY
NOTE: LH Side Shown In Illustration, RH Side Similar.

On Both Sides. Remove The Screws And The Sun Visor Clips.

Courtesy of FORD MOTOR COMPANY
If Equipped. Release The Clips And Remove The Rain Sensor Outer Covers.

Courtesy of FORD MOTOR COMPANY
If Equipped. Disconnect The Rear View Mirror Electrical Connector.

Courtesy of FORD MOTOR COMPANY
If Equipped. Disconnect The Rain Sensor Electrical Connector.

Courtesy of FORD MOTOR COMPANY
On Both Sides. Remove And Discard The Garment Hooks.
1. Open The Garment Hook Cover.
2. Remove The Screw.
Courtesy of FORD MOTOR COMPANY
Disconnect The Headliner Wiring Harness Connectors, Release The Wiring Harness Retainer And Position The Wiring Harness Aside.

Courtesy of FORD MOTOR COMPANY
NOTE: The Seat Backrest Latch Is Only Accessible When The Seat Cushion Is Raised.

NOTE: During Installation, The Striker Should Be In Its Lowest Position For The Latch To Engage.

Fold The Lh Rear Seat Backrest Down.
1. Raise The Seat Cushion.
2. Release The Backrest Latch.
3. Fold The Backrest Down.
Courtesy of FORD MOTOR COMPANY
Pull The Backrest Release Strap And Fold The Rh Rear Seat Backrest Down.

Courtesy of FORD MOTOR COMPANY
Release The Clips And Lower The Headliner.

Courtesy of FORD MOTOR COMPANY
Remove The Headliner.

Courtesy of FORD MOTOR COMPANY
