Typical EGR Cooler (All Others)

WARNING: This page is about a different car, the 2020 Ford F-550 Super Duty, 2020 Ford F-450 Super Duty, 2020 Ford F-350 Super Duty, 2020 Ford F-250 Super Duty, and 2020 Ford F-150. However, it is still accessible from the selected car via links, so may be relevant.
G13373209Courtesy of FORD MOTOR CO.
Item Number Description
1 - Engine Coolant Supply To The EGR Valve From The RH Valve Cover
2 - Exhaust Gas Outlet From The EGR Cooler To The Intake Manifold
3 - Exhaust Gas Inlet From The EGR Valve To The EGR Cooler
4 - EGR Cooler Assembly
