Hazard Flasher Switch: Removal

WARNING: This page is about a different car, the 2020 Ford F-150. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the FCIM. Refer to: Front Controls Interface Module (FCIM) .
  2. Release the tabs and remove the hazard flasher switch.
GFD465741Courtesy of FORD MOTOR COMPANY
