Side Parking Aid Camera: Removal

WARNING: This page is about a different car, the 2019 Ford F-550 Super Duty, 2019 Ford F-450 Super Duty, 2019 Ford F-350 Super Duty, and 2019 Ford F-250 Super Duty. However, it is still accessible from the selected car via links, so may be relevant.

For information on Ford Color Coded Illustrations refer to OEM Color Coding

Remove the exterior mirror. Refer to: Exterior Mirror .
Remove the exterior mirror weather shield.

Courtesy of FORD MOTOR COMPANY
1. Using a suitable tool, release the locking tabs.
2. Position the inside edge of the cover.
3. Remove the side parking aid camera cover.
Courtesy of FORD MOTOR COMPANY
Remove the side parking aid camera assembly.
1. Remove the screws.
2. Disconnect the connector.
Courtesy of FORD MOTOR COMPANY
Release the locking tabs and remove the upper camera bracket.

Courtesy of FORD MOTOR COMPANY
Remove the side parking aid camera.

Courtesy of FORD MOTOR COMPANY
