Front Parking Aid Camera: Removal
WARNING: This page is about a different car, the 2019 Ford F-550 Super Duty, 2019 Ford F-450 Super Duty, 2019 Ford F-350 Super Duty, and 2019 Ford F-250 Super Duty. However, it is still accessible from the selected car via links, so may be relevant.
For information on Ford Color Coded Illustrations refer to OEM Color Coding
- Remove the radiator grille. Refer to: Radiator Grille .
- Remove the screws and the front camera bracket.
- Remove the front parking aid camera.
