Typical Fuel Cooling System (All Others)
WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2018 Ford Transit-350 HD, 2018 Ford Transit-350, 2018 Ford Transit-250, 2018 Ford Transit-150, and 2018 Ford F-550 Super Duty. However, it is still accessible from the selected car via links, so may be relevant.
| Item | Number | Description |
|---|---|---|
| 1 | - | Fuel Tank |
| 2 | - | Fuel Rail |
| 3 | - | Fuel Cooler |
| 4 | - | Powertrain Secondary Cooling System Coolant Pump |
| 5 | - | Powertrain Secondary Cooling System Radiator |
| 6 | - | High Pressure Pump Bypass |
| 7 | - | High Pressure Pump |
| 8 | - | Fuel Pressure And Temperature Sensor |
| 9 | - | Secondary Fuel Filter |
| 10 | - | Fuel Conditioning Module |
