Connector End View (C2998) - STEERING WHEEL SWITCH, LH UPPER

Connector:	Description	Color	Harness	Base Part #	Service Pigtail
C2998	STEERING WHEEL SWITCH, LH UPPER	14K147			part# N/A	See Below

Courtesy of FORD MOTOR COMPANY

Terminal Part Number	Service Part Number	Size

Pin	Circuit	Gauge	Circuit Function	Qualifier	Terminal Part Number
1	RRH02 (*)	*	ILLUMINATION GROUND	N/A
2	LX105 (*)	*	SWITCH - STEERING WHEEL CONTROLS # A/D CHANNEL 1	N/A
3	RX101 (*)	*	SWITCH - STEERING WHEEL CONTROLS # RETURN LEFT (SW GND LEFT)	N/A
4	VLN04 (*)	*	ILLUMINATION FEED	N/A

Available Pigtail Kits

Pigtail Kit Part Number WPT-1013

Courtesy of FORD MOTOR COMPANY

Service Part Number:

9U2Z-14S411-TA

Gauge:

18

Pin material:

Silver

Cavities:

4

Vehicle Uses:

• Module - Auto Lamps
• Sensor - Sunload
