Liftgate Hinge: Removal

NOTE: Removal steps in this procedure may contain installation details.
  1. Remove the liftgate. Refer to: Liftgate .
  2. Lower the headliner.
    GFD305902Courtesy of FORD MOTOR COMPANY
  3. Remove the nuts and the liftgate hinges.

    Torque: 18 lb.ft (25 Nm)

GFD305940Courtesy of FORD MOTOR COMPANY
