Fuel Charging and Controls - Component Location
WARNING: This page is about a different car, the 2018 Ford EcoSport. However, it is still accessible from the selected car via links, so may be relevant.
| Item | Description |
| 1 | Throttle body Refer to: Throttle Body |
| 2 | High-pressure fuel pump Refer to:High-Pressure Fuel Pump |
| 3 | Fuel rail Refer to:Fuel Rail |
| 4 | Fuel injector Refer to:Fuel Injectors |
