Connector End View (C2999) - STEERING WHEEL SWITCH, LEFT

Connector:	Description	Color	Harness	Base Part #	Service Pigtail
C2998	STEERING WHEEL SWITCH, LEFT	BK	PIA	part# N/A	Not Available

Courtesy of FORD MOTOR COMPANY

Terminal Part Number	Service Part Number	Size

Pin	Circuit	Gauge	Circuit Function	Qualifier	Terminal Part Number
1	RX101 (BU-BK)	20	SWITCH - STEERING WHEEL CONTROLS # RETURN LEFT (SW GND LEFT)	N/A
2	*	*	Not Used	N/A
3	LX103 (RD)	20	SWITCH - STEERING WHEEL CONTROLS # A/D CHANNEL 1	N/A
4	LX104 (VT)	20	SWITCH - STEERING WHEEL CONTROLS # A/D CHANNEL 2	N/A
5	RRH02 (PK)	20	GROUND - INSTRUMENT PANEL STRUCTURE	N/A
6	LX105 (BK-BU)	20	SWITCH - STEERING WHEEL CONTROLS # A/D CHANNEL 3	N/A
7	*	*	Not Used	N/A
8	LX106 (BK)	20	SWITCH - STEERING WHEEL CONTROLS # A/D CHANNEL 4	N/A
9	*	*	Not Used	N/A
10	VLN04 (BN)	20	CTRL MOD. - IP/SWITCH ILLUMINATION	N/A
