Internal Gearshift Mechanism (Vehicles equipped with an 5.0L engine)
WARNING: This page is about a different variant/trim than selected.
| Item | Description |
|---|---|
| 1 | Shift shaft assembly |
| 2 | Reverse shift rail |
| 3 | Reverse shift fork |
| 4 | Shift fork pivot bolts |
| 5 | 1st/2nd shift rail |
| 6 | Reverse shift rail detent |
| 7 | 1st/2nd shift fork |
| 8 | 3rd/4th and 5th/6th shift rail |
| 9 | 5th/6th shift fork |
| 10 | 3rd/4th shift fork |
| 11 | Shift shaft assembly detents |
| 12 | Shift shaft assembly dampener |
| 13 | Shift shaft gate |
| 14 | Shift fork guide |
