Information and Entertainment System - Component Location
WARNING: This page is about a different car, the 2018 Ford Edge. However, it is still accessible from the selected car via links, so may be relevant.
 Courtesy of FORD MOTOR COMPANY
|
| Item |
Description |
| 1 |
FCIM |
| 2 |
APIM |
| 3 |
SYNC® microphone |
| 4 |
Rear door speaker |
| 5 |
AM/ FM/satellite (if equipped) antenna |
| 6 |
Audio input jack (if equipped) and USB port |
| 7 |
ACM |
| 8 |
USB cable |
| 9 |
Front door speaker |
| 10 |
Front door tweeter |
| 11 |
FCDIM |
| 12 |
GPSM |
