Passive Anti-Theft System (PATS) - Component Location
WARNING: This page is about a different variant/trim than selected.
 Courtesy of FORD MOTOR COMPANY
|
| Item |
Description |
| 1 |
BCM |
| 2 |
RTM |
| 3 |
PATS center antenna |
| 4 |
Keyless entry rear antenna |
| 5 |
Passive key backup starting location |
