Fuel Tank Draining
WARNING: This page is about a different variant/trim than selected.
For information on Ford Color Coded Illustrations refer to OEM COLOR CODING
Special Tool(s) / General Equipment
| 292-00004 Fuel Tanker 100 GPM | |
|---|---|
| Fuel Tank Draining Equipment |
Draining
WARNING:
Do not smoke, carry lighted tobacco or have an open flame of any type when working on or near any fuel-related component. Highly flammable mixtures may be present and may be ignited. Failure to follow these instructions may result in serious personal injury.
WARNING:
Do not carry personal electronic devices such as cell phones, pagers or audio equipment of any type when working on or near any fuel-related component. Highly flammable mixtures may be present and may be ignited. Failure to follow these instructions may result in serious personal injury.
NOTE:
Removal steps in this procedure may contain installation details.
- Refer to: Gasoline and Gasoline-Ethanol Fuel Systems Health and Safety Precautions
.
- Use Special Service Tool: 292-00004 Fuel Tanker 100 GPM.
- Refer to: Jacking and Lifting - Overview .
-
NOTE: Make sure that the components are installed to the position noted before removal.NOTE: Note the position of the components before removal.NOTE: Be prepared to collect escaping fluid.
- Use the General Equipment: Fuel Tank Draining Equipment
