Clutch Pedal Position (CPP) Switch: Removal
WARNING: This page is about a different variant/trim than selected.
NOTE:
Make sure that the clutch pedal remains in the rest position.
NOTE:
Removal steps in this procedure may contain installation details.
- Remove the LH instrument panel finish panel.
- Remove the retainers and the steering column opening trim panel.
- Disconnect and position aside the air sensor.
- Disconnect the electrical connector and remove CPP switch from the bracket.
