Timing Belt: Removal

WARNING: This page is about a different variant/trim than selected.
NOTE: Do not loosen or remove the crankshaft pulley bolt without first installing the special tools. The crankshaft pulley and the crankshaft timing sprocket are not keyed to the crankshaft. Before any repair requiring loosening or removal of the crankshaft pulley bolt, the crankshaft and camshafts must be locked in place by the special service tools, otherwise severe engine damage can occur.
  1. Remove the engine front cover. Refer to: Engine Front Cover  .
    GFD264899Courtesy of FORD MOTOR COMPANY
    1. Install Special Service Tool: 303-1605 Alignment Tool, Camshaft.
    2. NOTE: Only tighten the bolts finger tight at this stage.
    3. Torque

      : 89 lb.in (10 Nm)

    GFD264749Courtesy of FORD MOTOR COMPANY
  3. WARNING: Take extra care when handling the compressed spring.

    1. Rotate the timing belt tensioner clockwise.
    2. Install a suitable locking pin.
    3. Remove timing belt.

GFD264900Courtesy of FORD MOTOR COMPANY
