Steering Column Multifunction Switch LH: Removal

  1. WARNING: Before beginning any service procedure in this article, refer to Health and Safety Precautions . Failure to follow this instruction may result in serious personal injury.
  2. Remove the steering column shrouds. Refer to: Steering Column Shrouds .
  3. NOTE: The steering wheel is removed for clarity.
    NOTE: Make sure the component terminals are not bent or damaged.

    Remove the retainers and the LH steering column multifunction switch.

GFD197490Courtesy of FORD MOTOR COMPANY
