Intake Manifold: Removal
WARNING: This page is about a different variant/trim than selected.
NOTE:
Removal steps in this procedure may contain installation details.
- 1.
Refer to: Jacking and Lifting - Overview .
- 2.
Refer to: Battery Disconnect and Connect .
- 4.
Refer to: Quick Release Coupling . Use the General Equipment: Hose Clamp Remover/InstallerTorque:
Nut: 97 lb.in (11 Nm)
Clamps: 35 lb.in (4 Nm)
- 5.
Refer to: Quick Release Coupling .Torque:
1: 71 lb.in (8 Nm)
Clamps: 44 lb.in (5 Nm)
- 9.
Refer to: Quick Release Coupling .
