Brake Master Cylinder: Removal
NOTE:
Do not spill brake fluid on painted or plastic surfaces or damage to the surface may occur. If brake fluid is spilled onto a painted or plastic surface, immediately wash the surface with water.
NOTE:
Removal steps in this procedure may contain installation details.
-
WARNING: Before beginning any service procedure in this information, refer to Safety Warnings in General Information. Failure to follow this instruction may result in serious personal injury.
Refer to: Health And Safety Precautions .
- Refer to: Cowl Panel
.
- Torque: 89 lb.in (10 Nm)
- Torque: 18 lb.ft (25 Nm)
- Torque: 18 lb.ft (25 Nm)
