Cylinder Head - Plug-In Hybrid Electric Vehicle (PHEV): Removal
NOTE:
Do not loosen or remove the crankshaft pulley bolt without first installing the special tools as instructed in this procedure. The crankshaft pulley and the crankshaft timing sprocket are not keyed to the crankshaft. The crankshaft, the crankshaft sprocket and the pulley are fitted together by friction, using diamond washers between the flange faces on each part. For that reason, the crankshaft sprocket is also unfastened if the pulley bolt is loosened. Before any repair requiring loosening or removal of the crankshaft pulley bolt, the crankshaft and camshafts must be locked in place by the special service tools, otherwise severe engine damage can occur.
NOTE:
During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces, that enters the oil passages, coolant passages or the oil pan can cause engine failure.
-
WARNING: Before beginning any service procedure, refer to Safety Warnings in General Information. Failure to follow this instruction may result in serious personal injury.
Refer to: Health And Safety Precautions .
-
- Refer to: Jacking And Lifting - Overview .
- Refer to: Fuel System Pressure Release .
- Refer to: High Voltage Battery Disconnect and Connect - Plug-In Hybrid Electric Vehicle (PHEV) .
- Refer to: Battery Disconnect And Connect - Plug-In Hybrid Electric Vehicle (PHEV) .
- Refer to: Cooling System Draining, Filling And Bleeding .
- Refer to: Cooling System Draining, Filling And Bleeding .
- Refer to: Transmission Control Module (TCM) .
- Refer to: Intake Manifold
- Refer to: Valve Tappets .
-
NOTE: Transmission removed from graphic for clarity.
- Use the General Equipment: Trolley Jack
Use the General Equipment: Wooden Block
- Remove Special Service Tool: 303-F072 Support Bar, Engine., 303-290-05A Adapter for 303-290A.
