Steering Column Multifunction Switch LH: Removal

  1. 1.

    WARNING: Before beginning any service procedure in this article, refer to Health and Safety Precautions . Failure to follow this instruction may result in serious personal injury.

    Follow the health and safety precautions. Refer to: Health and Safety Precautions .

  1. 2.

    Remove the steering column shrouds. Refer to: Steering Column Shrouds .

  1. 3.

    NOTE: The steering wheel is removed for clarity.
    NOTE: Make sure the component terminals are not bent or damaged.

    Remove the retainers and the LH steering column multifunction switch.

GFD70706Courtesy of FORD MOTOR COMPANY
