| 1 |
* |
* |
Not Used |
|
| 2 |
* |
* |
Not Used |
|
| 3 |
* |
* |
Not Used |
|
| 4 |
VPK47 (VT) |
22 |
SENSOR - KEYLESS VEHICLE HANDLE REAR PASSENGER SIDE POWER/DATA |
|
| 5 |
VPK40 (WH-OG) |
22 |
SENSOR - KEYLESS VEHICLE HANDLE PASSENGER POWER/DATA |
|
| 6 |
* |
* |
Not Used |
|
| 7 |
VMP17 (YE-OG) |
22 |
SENSOR - PARKING AID # REAR # (RIGHT OUTER) |
|
| 8 |
VMP16 (YE-GY) |
22 |
SENSOR - PARKING AID # REAR # (RIGHT INNER) |
|
| 9 |
VMP30 (BN) |
22 |
SENSOR - PARKING AID # ACTIVE PARK ASSIST (AUTOPARK) REAR RIGHT SIDE |
|
| 10 |
* |
* |
Not Used |
|
| 11 |
* |
* |
Not Used |
|
| 12 |
VPK02 (VT-WH) |
22 |
CTRL MOD. - KEYLESS VEHICLE # ANTENNA HANDLE PASSENGER + |
|
| 13 |
VPK01 (BN-YE) |
22 |
CTRL MOD. - KEYLESS VEHICLE # ANTENNA HANDLE DRIVER + |
|
| 14 |
* |
* |
Not Used |
|
| 15 |
RPK06 (BU-WH) |
22 |
CTRL MOD. - KEYLESS VEHICLE # ANTENNA INTERIOR 2 (CENTER) - |
|
| 16 |
VPK06 (GY-VT) |
22 |
CTRL MOD. - KEYLESS VEHICLE # ANTENNA INTERIOR 2 (CENTER) + |
|
| 17 |
* |
* |
Not Used |
|
| 18 |
* |
* |
Not Used |
|
| 19 |
* |
* |
Not Used |
|
| 20 |
RPK39 (VT-OG) |
22 |
SENSOR - KEYLESS VEHICLE HANDLE |
|
| 21 |
VPK39 (GN-VT) |
22 |
SENSOR - KEYLESS VEHICLE HANDLE DRIVER POWER/DATA |
|
| 22 |
VPK46 (GY) |
22 |
SENSOR - KEYLESS VEHICLE HANDLE REAR DRIVER SIDE POWER/DAT |
|
| 23 |
VMP15 (YE-GN) |
22 |
SENSOR - PARKING AID # REAR # (LEFT OUTER) |
|
| 24 |
VMP14 (WH-OG) |
22 |
SENSOR - PARKING AID # REAR # (LEFT INNER OR MIDDLE) |
|
| 25 |
VMP29 (GN-OG) |
22 |
SENSOR - PARKING AID # ACTIVE PARK ASSIST (AUTOPARK) REAR LEFT SIDE |
|
| 26 |
LMP07 (BU-WH) |
22 |
CTRL MOD. - PARKING AID # SENSORS REAR + |
|
| 27 |
RMP07 (GN-WH) |
22 |
CTRL MOD. - PARKING AID # SENSORS REAR - |
|
| 28 |
RPK01 (WH-GN) |
22 |
CTRL MOD. - KEYLESS VEHICLE # ANTENNA HANDLE DRIVER - |
|
| 29 |
RPK02 (GY-YE) |
22 |
CTRL MOD. - KEYLESS VEHICLE # ANTENNA HANDLE PASSENGER - |
|
| 30 |
* |
* |
Not Used |
|
| 31 |
* |
* |
Not Used |
|
| 32 |
* |
* |
Not Used |
|
