Brake Pedal Control Switch: Notes

NOTE: For information on Ford Color Coded Illustrations refer to COLOR-CODING - FORD .

NOTE: Steering wheel removed for clarity.

Fig 1: Brake Pedal Control Switch With Screw And Torque Specifications

Courtesy of FORD MOTOR CO.

Item	Part Number	Description
1	W715057	Screw
2	9G604	Brake pedal control switch
