Brake Booster: Removal
- Refer to: REMOTE BRAKE FLUID RESERVOIR .
- Torque:
159 lb.in (18 Nm)
- Torque:
159 lb.in (18 Nm)
-
NOTE: Do not service the brake pedal or brake booster without first removing the stoplamp switch. This switch must be removed with the brake pedal in the at-rest position. The switch plunger must be compressed for the switch to rotate in the bracket. Attempting to remove the switch when the plunger is extended (during pedal apply) will result in damage to the switch.
Refer to: STOPLAMP SWITCH .
- Torque:
18 lb.ft (25 Nm)
