OEM Wiring Diagrams -- (Except Hybrid)
>>
Horn/Cigar Lighter
>>
With 110V Power Inverter
With 110V Power Inverter
Fig 1: Horn_Cigar Lighter Wiring Diagram - With 110V Power Inverter
Courtesy of FORD MOTOR CO.
Courtesy of FORD MOTOR CO.
