Roof Opening Panel
>>
MKZ Without Panoramic Roof
MKZ Without Panoramic Roof
Fig 1: Roof Opening Panel Wiring Diagram - MKZ, Without Panoramic Roof
Courtesy of FORD MOTOR CO.
