F67, F68, F69

WARNING: This page is about a different car, the 2012 Ford Focus. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Power Distribution Circuit Diagram - F67, F68 And F69
G07918699Courtesy of FORD MOTOR CO.
