Without Door Modules

WARNING: This page is about a different car, the 2012 Ford Focus. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Interior Lamps Circuit Diagram - Without Door Modules
G07918792Courtesy of FORD MOTOR CO.
