With Driver/Passenger Door Module

WARNING: This page is about a different car, the 2012 Ford Focus. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Heated Window Circuit Diagram (With Driver/Passenger Door Module)
G07918774Courtesy of FORD MOTOR CO.
