Parking, Rear and License Lamps
>>
With Manual Transmission
With Manual Transmission
Fig 1: Parking, Rear And License Lamps Wiring Diagram (With Manual Transmission)
Courtesy of FORD MOTOR CO.
Courtesy of FORD MOTOR CO.
