Parking Brake Control: Removal

NOTE: Steps in the removal procedure may contain installation details.

All vehicles

Remove the floor console. Refer to INSTRUMENT PANEL AND CONSOLE .
With the vehicle in NEUTRAL, position it on a hoist. Refer to JACKING & LIFTING .
- To install, tighten to 25 Nm (18 lb-ft).
All-Wheel Drive (AWD) vehicles
- To install, tighten to 25 Nm (18 lb-ft).
All vehicles
- To install, tighten to 11 Nm (97 lb-in).
NOTE: During installation, make sure the cable seal is fully seated.

Visual check.
- To install, tighten to 30 Nm (22 lb-ft).
