Removal and Installation

  1. Remove the RH and LH A-pillar trim panels. Refer to INTERIOR TRIM -- EXPLODED VIEW .
  2. Remove the upper instrument panel trim panel. Refer to INSTRUMENT PANEL FINISH PANEL - Center, Upper .
  3. Remove the two bolts and the defroster grille panel.
    • Disconnect the electrical connector.
    • To install, tighten to 3 Nm (27 lb-in).
      G08618866
  4. To install, reverse the removal procedure.
