Cushion Frame From Underneath

WARNING: This page is about a different car, the 2014 Lincoln MKX and 2014 Ford Edge. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying Wire Harness Main Bundle, OCS Weight Sensor Bolt Wire Harness Takeout And Side Air Bag Electrical Connector
G09299035Courtesy of FORD MOTOR CO.
Item Description
1 Wire harness main bundle
2 OCS weight sensor bolt wire harness takeout
3 Side air bag electrical connector
