HVAC Module

WARNING: This page is about a different car, the 2012 Ford Pickup, 2012 Ford F550 Super Duty, 2012 Ford F450 Super Duty, and 2012 Ford Cab & Chassis. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Identifying HVAC Module With Screw

Courtesy of FORD MOTOR CO.

Item	Part Number	Description
1	W506823	HVAC module screw (4 required)
2	19980	HVAC module
