Turbocharger Oil Supply Tube LH: Removal
WARNING: This page is about a different car, the 2015 Ford F-150. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
Whenever turbocharger air intake system components are removed, always cover open ports to protect from debris. It is important that no foreign material enter the system. The turbocharger compressor vanes are susceptible to damage from even small particles. All components should be inspected and cleaned, if necessary, prior to installation or reassembly.
- 1.
Remove the turbocharger LH. REFER to: Turbocharger LH .
- 2.
Remove the lower turbocharger oil manifold assembly bolt and the turbocharger oil manifold assembly.
