Turbocharger Coolant Supply Tube LH: Removal
WARNING: This page is about a different car, the 2015 Ford F-150. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
Whenever turbocharger air intake system components are removed, always cover open ports to protect from debris. It is important that no foreign material enter the system. The turbocharger compressor vanes are susceptible to damage from even small particles. All components should be inspected and cleaned, if necessary, prior to installation or reassembly.
- 1.
With the vehicle in NEUTRAL, position it on a hoist. REFER to: Jacking and Lifting - Overview .
- 3.NOTE: Vehicles come with a skid plate or a splash shield.NOTE: Skid plate shown in illustration, splash shield similar.
If equipped, remove the bolts and the skid plate or splash shield.
- 4.
Drain the cooling system. REFER to: COOLING SYSTEM DRAINING AND VACUUM FILLING .
