Battery Cables - 2.7L EcoBoost (238kW 324PS): Removal
WARNING: This page is about a different car, the 2015 Ford F-150. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
This procedure provides information about routing, retaining points and connectors of the cable. It does not include the steps for removing components to gain access to the cable.
- 1.
With the vehicle in NEUTRAL, position it on a hoist. Refer to: Jacking and Lifting - Overview .
- 2.
Disconnect the battery. Refer to: Battery Disconnect and Connect .
- 3.
- 1.
Torque: 80 lb.in (9 Nm)
- 2.
Torque: 55 lb.in (6.2 Nm)
- 3.
Torque: 71 lb.in (8 Nm)
- 4.
Torque: 55 lb.in (6.2 Nm)
- 5.
Torque: 89 lb.in (10 Nm)
- 1.
