Oil Pump: Removal

WARNING: This page is about a different car, the 2014 Ford F-150. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the timing drive components. For additional information, refer to TIMING DRIVE COMPONENTS .
  2. Remove the oil pan. For additional information, refer to OIL PAN .
  3. Remove the oil pump screen and pickup tube support bracket nut.
    Fig 1: Locating Oil Pump Screen And Pickup Tube Support Bracket Nut With Torque Specifications
    G06280817Courtesy of FORD MOTOR CO.
  4. Remove the 2 bolts and the oil pump screen and pickup tube.
    Fig 2: Locating Oil Pump Screen And Pickup Tube Mounting Bolt
    G09390153Courtesy of FORD MOTOR CO.
  5. Remove the 2 upper bolts, the 2 lower stud bolts and the oil pump.
    Fig 3: Locating Oil Pump Upper Bolts And Lower Stud Bolts
    G06518264Courtesy of FORD MOTOR CO.
