F1, F2, F3, F5, F6, F7, F8, F21, F26

WARNING: This page is about a different car, the 2014 Ford F-150. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Power Distribution/BCM - Wiring Diagram (F1, F2, F3, F5, F6, F7, F8, F21 And F26)

Courtesy of FORD MOTOR CO.
