With Power Equipment - Super Cab

WARNING: This page is about a different car, the 2014 Ford F-150. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Interior Lamps - Wiring Diagram (Without Power Equipment - Super Cab)
G09257616Courtesy of FORD MOTOR CO.
