Cruise Control: 5.0L/6.2L

WARNING: This page is about a different car, the 2013 Ford F-150. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Cruise Control Circuit Diagram - 5.0L/6.2L
G08747104Courtesy of FORD MOTOR CO.
