Vehicle Emission Vacuum Routing: 3.7L
WARNING: This page is about a different car, the 2013 Ford Mustang. However, it is still accessible from the selected car via links, so may be relevant.
Courtesy of FORD MOTOR CO.
| Item |
Part Number |
Description |
| 1 |
6A505 |
LH valve cover |
| 2 |
9R530 |
ACL outlet tube |
| 3 |
9G866 |
EVAP canister purge valve |
| 4 |
9424 |
Intake manifold |
| 5 |
6A666 |
PCV valve |
| 6 |
6582 |
RH valve cover |
| 7 |
9002 |
Fuel tank |
| 8 |
- |
FTP sensor (part of 9E325) |
| 9 |
9034 |
Fuel tank filler pipe |
| 10 |
9E857 |
EVAP canister |
