Removal And Installation: Radiator: Removal
WARNING: This page is about a different car, the 2013 Ford Mustang. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
Removal steps in this procedure may contain installation details.
- Remove the front bumper cover. Refer to BUMPERS .
- Drain the SC cooling system. Refer to SUPERCHARGER COOLING SYSTEM DRAINING, FILLING AND BLEEDING .
- Remove the ACL housing and the ACL inlet pipe. Refer to INTAKE AIR DISTRIBUTION & FILTERING .
