Fog Lamp Bulb: Removal

WARNING: This page is about a different car, the 2013 Ford Mustang. However, it is still accessible from the selected car via links, so may be relevant.

WARNING: The bulb contains gas under pressure. The bulb may shatter if the glass envelope is scratched or if the bulb is dropped. Handle the bulb only by its base. Avoid touching the glass envelope. Failure to follow these instructions may result in personal injury.

NOTE: The fog lamp bulb should not be removed from the fog lamp until just before a new bulb is installed. Removing the bulb for an extended period of time can affect fog lamp bulb performance. Contaminants can enter the fog lamp where they can settle on the lens and reflector. Never turn on the fog lamps with the bulb removed.

NOTE: Make sure the headlamp switch and the ignition switch are in the OFF position.

3.7L vehicles

With the vehicle in NEUTRAL, position it on a hoist. Refer to JACKING & LIFTING .
Three on each side.
- To install, tighten to 3.2 Nm (28 lb-in).
To install, tighten to 1.9 Nm (17 lb-in).
5.0L Vehicles

NOTE: The fog lamp bulb can be accessed without removing the front bumper cover.
With the vehicle in NEUTRAL, position it on a hoist. Refer to JACKING & LIFTING .
Three on each side.
- To install, tighten to 3.2 Nm (28 lb-in).
To install, tighten to 3.2 Nm (28 lb-in).
To install, tighten to 3.2 Nm (28 lb-in).
GT500 vehicles
With the vehicle in NEUTRAL, position it on a hoist. Refer to JACKING & LIFTING .
On each side.
- To install, tighten to 3.2 Nm (28 lb-in).
To install, tighten to 3.2 Nm (28 lb-in).
To install, tighten to 3.2 Nm (28 lb-in).
On each side.
