Front Cover Radial Seal: Installation

WARNING: This page is about a different car, the 2013 Ford F-150. However, it is still accessible from the selected car via links, so may be relevant.
  1. Using the Water Tube Seal Installer, install the front cover radial seal.
    • Position the front cover radial seal on the Water Tube Seal Installer.
    • Position the Water Tube Seal Installer into the engine front cover.
    • Using a brass hammer, tap the Water Tube Seal Installer until the front cover radial seal bottoms out.
      Fig 1: Installing Front Cover Radial Seal Using Water Tube Seal Remover
      G08337517Courtesy of FORD MOTOR CO.
  2. Inspect the front cover radial seal for proper installation or damage.
  3. Install the coolant pump. For additional information, refer to ENGINE COOLING SYSTEM .
  4. Install the A/C compressor belt. For additional information, refer to ACCESSORY DRIVE BELT .
