Cruise Control: 3.7L

WARNING: This page is about a different car, the 2012 Ford Pickup. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Cruise Control Circuit Diagram (3.7L)
G07907134Courtesy of FORD MOTOR CO.
