Seat Armrest - 60 Percent
WARNING: This page is about a different car, the 2012 Ford Pickup. However, it is still accessible from the selected car via links, so may be relevant.
| Item | Part Number | Description |
|---|---|---|
| 1 | 63804 | Shield |
| 2 | N803678 | Shield retainer (2 required) |
| 3 | W506824 | Cupholder screws (3 required) |
| 4 | 67336 | Armrest frame |
| 5 | 7E391 | Cupholder bezel cover |
| 6 | 67336 | Cupholder bezel |
| 7 | 13562 | Cupholder |
| 8 | W506824 | Cupholder bezel screw |
| 9 | 60508/67273 | Armrest cover/foam pad |
